CAPACITY / SPAN

• CTM motorized 1 – 10 Ton /Up to 60′ Span
• CTP push 1 – 5 Ton/Up to 35′ Span
• CTG geared 1 – 5 Ton/Up to 50′ Span

SERVICE CLASS

• Class C

COMPLIANCE

• Crane Manufacturers Association of America (CMAA)
• National Electric Code (NEC)
• American National Standards Institute (ANSI/ASME)

CRANE SYSTEM INCLUDES

• End trucks come standard with drives, brakes, bumpers, drop stops, and rail sweeps
• Crane control panel with adjustable Electronic Acceleration Control (EAC) and thru-the-door lock-out disconnect switch
• Crane wiring installed in code-compliant conduit
• Standard bridge beam assembly with bracing and capacity labels
• Trolley hoist supplied with operator control pendant
• Documentation including assembly and installation instructions, crane operator’s guide and owner’s manuals
• Touch-up paint
• One year warranty

STANDARD FEATURES

• Bolted assembly for quick and easy installation
• Minimal welding required
• Most wiring connections are factory installed or plug-in type
• Rail sweeps
• Drop stops
• Rubber bumpers

CAPABILITIES

• Crane speeds: 40, 80, 120 ft/min single speed, or variable speed
• Motorized trolley speeds: 40 or 80 ft/min single speed, 80/20 ft/min dual speed or variable speed
• 3 phase voltages: 208, 230/460, 380, 575 (50 or 60 Hz)
• Suitable for use on ASCE crane rail or square bar
• CTM motorized cranes are available with plug and play connections for easy installation

OPTIONS

• Variable frequency control or two speed, radio remotes
• Roving pendants
• Multiple hoist variations and options
• Plug and Play connections
• Runway electrification
