Telescoping Cranes

Designed to reach into adjoining bays, telescope through open doors and outside of buildings, when you need move the load on your crane into an adjoining bay or through an open door you can do so by utilizing telescoping cranes. Designed with a second bridge beam, telescoping cranes operate with a series of trolleys and kick-up devices that allow the underhung beam to telescope. This unique feature can solve many material handling challenges. Standard capacities range from 1 through 10-tons. Larger capacities are available if an application requires it.

Telescoping cranes can be equipped with all the options of a standard overhead bridge crane including free traveling pendant stations, radio controls, 2 speed and variable controls and travel alarms and lights. Additionally, zoning controls can be added to limit the travel of the bridge crane when the telescoping bridge is in the extended position.

Runway beams and increased sizes of wheels and end trucks must be considered in telescoping cranes’ design due to the additional weight of the secondary beam and the cantilevered load that transfers most of the weight of the main girder to a single runway. CraneWerks engineers are experienced in working with the design challenges of telescoping cranes and can offer quick answers to your questions as they arise. Contact us today to begin communications concerning your telescoping cranes.
